AS1428.1 pull down grab rail with an integrated toilet roll holder.
This 850mmL x 315mmH rail is built from 1.2mm #304 stainless steel tubing (32mmØ) with a 2.5mm formed #304 stainless steel mounting bracket and brace, and a 12.5mmØ stainless steel toilet roll holder bar, all finished in satin stainless steel. The grab rail measures 215mmH from outer edge to edge; the toilet roll holder is 168mmL, sitting 50mm below the underside of the upper rail and holding a standard roll of up to 230 sheets. The mounting bracket is 104mmW x 315mmH x 30-50mmD x 2.5mmT with 7 mounting holes at 8mmØ.
The unit is seamless welded and polished, and stores upright when not in use. Its materials and construction meet AS1428.1 force requirements, able to withstand a force of 1100Nm applied at any position and direction without deformation.
Features:
- 1.2mm #304 stainless steel tubing, 32mmØ
- 12.5mmØ stainless steel toilet roll holder bar
- Satin stainless steel finish
- 850mmL x 315mmH overall, 215mmH grab rail
- Toilet roll holder holds up to 230 sheets
- Seamless welded and polished, stores upright
- AS1428.1 compliant when installed per guidelines (1100Nm force rated)
SKU: MLR50TPH
