A lead free, WaterMark certified ball valve that presses onto copper on one side and threads into a female fitting on the other. The male iron (MI) end screws straight into valves, meters, equipment or female threaded fittings with no separate adaptor, so a copper press line can be isolated and transitioned to thread in one component.
Full bore construction means no flow restriction through the valve. The body is DR lead free brass, and the lever handle gives a positive quarter turn with a clear open or closed position that is easy to read and easy to grip in tight plant rooms and risers. Each valve is pressure tested before dispatch.
Press with Viega, Rothenberger, Novopress, Kempress, Rems or V-profile tooling only. Seal the MI thread with PTFE tape or thread sealant suited to potable water.
Specifications
| Connection | Copper press x male iron thread (CU x MI) |
| Sizes | DN20 x 20MI (R 3/4"), DN25 x 25MI (R 1") |
| Handle | Lever |
| Bore | Full bore |
| Max working pressure | 2500kPa |
| Body | DR lead free brass |
| Press tooling | Viega, Rothenberger, Novopress, Kempress, Rems and V-profile tools only |
Features
- Copper press inlet, no soldering
- Male iron outlet for direct connection to female threads
- Full bore for unrestricted flow
- Lever handle, quarter turn
- DR lead free brass body
- Pressure tested
- Rated to 2500kPa
Compliance
WaterMark certified and lead free, to suit NCC Volume Three requirements for drinking water installations.
Applications: Hot and cold water isolation where copper press pipework connects to threaded valves, meters, pumps, filters and equipment.
