The Hyjet Minipit is a pre-assembled stormwater pump pit with a Class A galvanised grate and pre-plumbed vortex pump, for low-lying backyards, construction sites and temporary setups where surface water pools. The inlet is installed on site. Not suitable for raw sewage.
Select the configuration you need from the options above. The models covered by this listing are:
| SKU | Option | Description |
|---|---|---|
| MMP600-V180 | HV180-AV Vortex Pump | MINIPIT 600 - 710mm x 710mm x 660mm Deep with class A galvanised grate, pre-plumbed with HV180-AV vortex submersible pump and 32mm outlet |
| MMP600-V750 | HV450-AV Vortex Pump | MINIPIT 600 - 710mm x 710mm x 660mm deep with class A galvanised grate, pre-plumbed with HV450-AV submersible pump and 40mm outlet |
Specifications
| Brand | Hyjet |
| Grate | Class A galvanised steel |
| Pump | Cast iron vortex with automatic float switch |
| Power supply | 240V 10A |
| Max temperature | 40°C |
| Solids handling | up to 25mm |
Features
- Pre-plumbed and ready to set in place
- Non-trafficable areas
Notes
- The manufacturer datasheet with performance curves and dimensions is available under Downloads.
Need help sizing a pump? Call our team on 0414 040 452 or email sales@plumbersupplies.com.au.
